Outdoor Aluminum LED Screen IP65 For Advertising Billboard

Outdoor A Series Aluminum LED Display

Feature Description
- High brightness and super energy saving
- Ultra-light and ultra-thin
- Simple structure, full wireless, hard link, front and rear maintenance
- Good heat dissipation, no need for air conditioning
- V0 Fire-Retardant Material
- Modular aluminum bottom shell, flame retardant and fireproof, waterproof grade IP65

Save 30% Energy – Dual power supply + optimized circuits. Our outdoor aluminum LED display delivers exceptional brightness while consuming up to 30% less energy. Lower bills, greener operation, zero compromise.

Outdoor A Series Aluminum LED Display

Fanless Self-Cooling – Modular design + silent thermal convection. No fans, no AC, no noise. Runs cool and quiet naturally – saving you energy and maintenance costs.

Outdoor A Series Aluminum LED Display

Front & Rear Maintenance – Service from either side. Simplify operation, slash installation complexity, and cut maintenance time in half. Works anywhere – even in tight spaces.

Outdoor A Series Aluminum LED Display

Integrated Power Box – All-in-one design. Hidden interfaces. Zero cable clutter. Clean front, clean back, clean install. Professional appearance with professional protection.

Outdoor A Series Aluminum LED Display

IP65 Dustproof & Waterproof – Front & Rear

Outdoor Fixed Installation Led Displays P4.4 P6.67 P8 P10 Front Service Aluminum Energy Saving 960X960Mm Led Video Wall IP66 5

Ultra-Lightweight – <26KG/m². 40% lighter than competitors. Less structural stress. Lower shipping costs. Faster installation. Light weight, heavy performance.

Outdoor Fixed Installation Led Displays P4.4 P6.67 P8 P10 Front Service Aluminum Energy Saving 960X960Mm Led Video Wall IP66 6

Specifications

Cabinet size	640(W)640(H)80mm(T)		960(W)640(H)80mm(T)		960(W)960(H)80mm(T)
Cabinet resolution	256*256dots	208*208dots	384*256dots	312*208dots	240*240dots	192*192dots	144*144dots	120*120dots	96*96dots
Pixel pitch	2.5mm	3.076mm	2.5mm	3.076mm	4mm	5mm	6.67mm	8mm	10mm
Pixel density	160000dots/m²	105625dots/m²	160000dots/m²	105625dots/m²	62500dots/m²	40000dots/m²	22500dots/m²	15625dots/m²	10000dots/m²
LED specification	1415 SMD	1415 SMD	1415 SMD	1415 SMD	1921 SMD	1921 SMD	2727 SMD	2727 SMD	2727 SMD
Module size	160*640mm	160*640mm	160*640mm	160*640mm	160*960mm	160*960mm	160*960mm	160*960mm	160*960mm
Unit resolution	64*256dots	52*208dots	64*256dots	52*208dots	40*240dots	32*192dots	24*144dots	20*120dots	16*96dots
Weight	13kg±2kg	13kg±2kg	19kg±2kg	19kg±2kg	21.5kg±2 kg	21.5kg±2 kg	21.5kg±2 kg	21.5kg±2 kg	21.5kg±2 kg
Material	Aluminum
Maintenance mode	Front and rear maintenance
Best viewing distance	≥2.5m	≥3.076m	≥2.5m	≥3.076m	≥4m	≥5m	≥6.67m	≥8m	≥10m
Pixel configuration	1R1G1B
Best viewing angle	120°(H)/120°(V)
Brightness	≥4500cd/㎡				≥6000cd/㎡
Color temperature	3500-9300K adjustable
Correcting	Support correction
Deviation	≤3%
Homogeneity	≥97%
Max Power consumption	750W/㎡
Ave power consumption	250W/㎡
Drive type	1/16 Scanning	1/13 Scanning	1/16 Scanning	1/13 Scanning	1/10Scanning	1/8 Scanning	1/6 Scanning	1/5 Scanning	1/2 Scanning
Driving device	IC Constant Current driver
Working voltage	AC200-240V
Operating environment	Outdoor
Refresh frequency	≥3840Hz
Framing frequency	50/60Hz
IP Grade	IP65
Storage temperature	-40℃~60℃
Working temperature	-20℃~50℃
Operation humidity	10%～90%
MTBF	≥5000 hours
Life span	≥50000 hours
Blind spot rate	≤1/10000

Tag:

Place of Origin:	CHINA
Brand Name:	CONWIN
Certification:	CE,ROHS

Minimum Order Quantity:	1sqm
Packaging Details:	wooden box or carton
Delivery Time:	5-8 working days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	2000sqm/month

Media Available:	Photo, Video	Gray Scale:	8bits Input, Correction With 14bits
Cabinet Size:	960mm X 960mm	Led Brand:	Nationstar
Installation Type:	Wall-mounted / Hanging	Certifications:	CE/ROHS/EMC/TUV/UL/CCC/FCC/ISO
IP:	IP66	Refresh Rate:	3840Hz
Contrast Ratio:	15000:1	Weight:	25kg
Working Voltage:	220V Or 110V
