Indoor Fixed Installation Led Video Wall P2/P2.5 Seamless Splicing Led Screen Fine Video Quality

Basic Information
Place of Origin: China
Brand Name: CONWIN
Certification: CE,ROHS
Model Number: E2
Minimum Order Quantity: 1sqm
Packaging Details: wooden box or carton
Delivery Time: 5-8 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 2000sqm/month
Pixel Pitch: 1.25mm P1.53mm P1.86mm Lifespan: 100000 Hours
Used For: Indoor Usage: Indoor
Thckness: 80mm Connectivity: HDMI, VGA, DisplayPort
Pixel Configuration: 1R1G1B/SMD2121 Black Lamp Resolution: 1920 X 1080
Maintenance: Front/rear Size: Customized
Cabinet Dimension: 640x480mm Thickness: 80mm
Input: AC 110/220V+-10% Operating Life: >50000hours
Display Image: Video, Image, Picture, Flash
Highlight:

Seamless Splicing Led Video Wall

,

P2/P2.5 Led Video Wall

,

Fine Quality Led Video Wall

Product Description

Manufacturer Outdoor/indoor High quality P0.9/P1.2/1.5/1.8/P2/P3 Pixel pitch led curved screen conference studio led electronic monitoring

High quality lamp tubes with high utilization of lamp brightness, ensuring the service life of the lamp tubes

Selected PWM drive IC, natural grayscale transition, high refresh, realistic display, and vibrant colors

Lightweight, easy to install and disassemble

Capable of single point and single light maintenance, with low cost

Using low-voltage method to drive LED, with uniform light emission and low power consumption

Indoor Fixed Installation Led Video Wall P2/P2.5 Seamless Splicing Led Screen Fine Video Quality 0

Indoor Fixed Installation Led Video Wall P2/P2.5 Seamless Splicing Led Screen Fine Video Quality 1
Indoor Fixed Installation Led Video Wall P2/P2.5 Seamless Splicing Led Screen Fine Video Quality 2
Indoor Fixed Installation Led Video Wall P2/P2.5 Seamless Splicing Led Screen Fine Video Quality 3


Indoor Fixed Installation Led Video Wall P2/P2.5 Seamless Splicing Led Screen Fine Video Quality 4
Indoor Fixed Installation Led Video Wall P2/P2.5 Seamless Splicing Led Screen Fine Video Quality 5
Indoor Fixed Installation Led Video Wall P2/P2.5 Seamless Splicing Led Screen Fine Video Quality 6
Indoor Fixed Installation Led Video Wall P2/P2.5 Seamless Splicing Led Screen Fine Video Quality 7
Indoor Fixed Installation Led Video Wall P2/P2.5 Seamless Splicing Led Screen Fine Video Quality 8



Product Parameters

Pixel Pitch
P1.25
P1.86
P2
P2.5
P3
P3.076
P4
P5
LED Type
1515
1515
1515
1515
2121
2121
2121
2121
Density(pixels/sqm)
640000
289050
250000
160000
111111
105688
62500
40000
Brightness(cd/sqm)
800~1000cd/sqm
Scan Method
1/64
1/43
1/40
1/32
1/16
1/26
1/20
1/16
Module Size
320*160mm
Module Resolution
256*128
172*86
160*80
128*64
106*53
104*52
80*40
64*32
Cabinet Size
640*480mm
Cabinet Resolution
512*384
344*258
320*240
256*192
213*160
208*156
160*120
128*96
Cabinet Weight
5.5kg/pc
Max Power
600w/sqm
Avg Power
200w/sqm
Maintance Mode
Full front maintenance
Cabinet Material
Die-casting magnesium alloy
Refresh Rate
3840HZ
Protective Grades
IP40
View Angle
140°/140°
Operating Temperature
-20℃~+50℃
Frame Frenquency
≥60HZ
Life Time
100000hours
