| Place of Origin: | China |
|---|---|
| Brand Name: | Conwin LED Display |
| Certification: | FCC, CE, ROHS |
| Model Number: | MI-X1.5 |
| Minimum Order Quantity: | 1sqm |
| Price: | Negotiable |
| Packaging Details: | Wooden box |
| Delivery Time: | 15 days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 1,000sqm/month |
| Pixel Pitch: | P1.5625mm | Material: | Die-casting Aluminum |
|---|---|---|---|
| Size: | 600X337.5mm | Thickness: | 27.5mm |
| Weight: | 4.5kg | Refresh: | 3840hz |
| Highlight: | COB P1.5 LED Screen,4K P1.5 LED Screen |
||
2K 4K COB P1.5 LED Display TV Support Power and Signal Dual-Backup Design
MI-X series(MI-X1.5) COB P1.5mm LED display panel with perfect HD 2K 4K image/video quality performance, widely using in indoor HD TV, TV studio, schools, conference room, public security, malls and other fields.
Features and Advantages:
- Light weight and thin thickness
Save installation time and cost,also delivery cost
- Wide viewing angle
Both 170 degree from horizontal&vertical for the viewing angle
- Ultra High Definition
It delivers a truly amazing picture with extraodinary pixels producing an image that is HD quality in LED screen
- High contrast ration
Excellent performance when works on the color
- High refresh rate
Could reach 3840hz
- Support dual-backup design
two sets Power and card(signal) in cabinet in case
- 2K 4K LED TV cabinet
Parameters:
| Pixel pitch | mm | 1.5625 |
| Brightness | nits | >=600 |
| Color temperature | deg.k | 1,000-18,500 |
| Viewing angle - Horizontal | deg. | 170(+85/-85) |
| Viewing angle - Vertical | deg. | 170(+85/-85) |
| Cabinet weight | kg | 4.5 |
| Cabinet width | mm | 600 |
| Cabinet height | mm | 337.5 |
| Cabinet depth | mm | 27.5 |
| Cabinet material | Die-casting Aluminum | |
| Operating temperature range | deg. C | -20 to 60 |
| Operating humidity range | HR | 10％ to 85％ |
| Pixel type and configuration | R/G/B | Inversion |
| Pixel matrix per cabinet | dots | 384X216 |
| LED module size(WXH) | mm | 150X168.75 |
| Module resolution(WXH) | dots | 96X108 |
| Gray scale | Levels | 65536 levels per colour |
| Brightness control | Levels | 100 |
| Frame rate | Hertz | 60 |
| Display refresh rate | Hertz | 3840 |
| Input voltage | VAC | 110/240 |
| Input power frequency | Hertz | 50/60 |
| Power (max/avg) | Watts per sq.m | 450/150 |
| Grey scale level | bits | 16 |
