High Resolution SMD Indoor LED Display Screen P1.5 P1.56mm

High Resolution SMD Indoor LED Display Screen P1.5 P1.56mm
High Resolution SMD Indoor LED Display Screen P1.5 P1.56mm
High Resolution SMD Indoor LED Display Screen P1.5 P1.56mm High Resolution SMD Indoor LED Display Screen P1.5 P1.56mm High Resolution SMD Indoor LED Display Screen P1.5 P1.56mm High Resolution SMD Indoor LED Display Screen P1.5 P1.56mm
Basic Information
Place of Origin: China
Brand Name: Conwin LED Display
Certification: CE-EMC, CE-LVD, RoHS, ETL, FCC
Model Number: MI-V1.56
Minimum Order Quantity: 1sqm
Price: Negotiable
Packaging Details: Wooden box
Delivery Time: 15 days
Payment Terms: T/T, L/C
Supply Ability: 1,000sqm/month
Contact Now
Pixel Pitch: 1.56mm Size: 400X450X60mm
Material: Die-casting Aluminum Weight: 5kg
LED Lamp: SMD System: Nova
Highlight:

SMD indoor led display screen

,

indoor led display screen P1.5

,

P1.56mm high resolution led screen

High Resolution P1.5 P1.56mm Indoor Using LED Video Wall Display



Quick Details:

- Pixel pitch distance: 1.56mm, Surface mounted device(SMD)

- Dimensions: 400X450(width x height)

- Wide viewing angle

- Recommended minimum viewing distance: 1.5m.

- Die-casting Aluminum cabinet weight: 5kg/panel.



Features and Advantages:

-User Friendly Design

 Front magnetic module, simple maintenance, take off module in a few seconds

 High Resolution SMD Indoor LED Display Screen P1.5 P1.56mm 0



-Absolute 2K 4K video Quality, stunning visual performance

 Could do assemble HD P1.5 P1.56mm LED cabinets easily, make a cinema LED video wall or 2K 4K TV.

High Resolution SMD Indoor LED Display Screen P1.5 P1.56mm 1High Resolution SMD Indoor LED Display Screen P1.5 P1.56mm 2



-Cercified Low radiation and noiseless technology

 Passed the EMC-class B standard with noiseless technology to ensure silent environment capabilities.



Application:



MI-V series HD indoor using LED video wall screen include MI-V1.25(P1.25mm),MI-V1.56(P1.56mm) and MI-V1.66(P1.66mm)

The premium option for high end indoor led display, applied for high profile hotels, securities companies, schools, stage, public security, shopping centers and other fields.

High Resolution SMD Indoor LED Display Screen P1.5 P1.56mm 3High Resolution SMD Indoor LED Display Screen P1.5 P1.56mm 4

High Resolution SMD Indoor LED Display Screen P1.5 P1.56mm 5

High Resolution SMD Indoor LED Display Screen P1.5 P1.56mm 6



Parameters:
Pixel pitch mm 1.56
Brightness nits 500
Color temperature deg.k 2000 ~ 9500
Viewing angle - Horizontal deg. 160(+70/-70)
Viewing angle - Vertical deg. 160(+70/-70)
Cabinet weight kg 5.5
Cabinet width mm 400
Cabinet height mm 450
Cabinet depth mm 62
Cabinet material   Die-Aluminum
Operating temperature range deg. C -10 to 60
Operating humidity range HR 30％ to 75％
Pixel type and configuration R/G/B SMD 3in1
Pixel pitch mm 1.56
Pixel matrix per cabinet   256x288
LED module size(WXH) mm 200X150
Module resolution(WXH) dots 128X96
Gray scale Levels 65536 levels per colour
Brightness control Levels 100
Frame rate Hertz 60
Display refresh rate Hertz 3840
Input voltage VAC 110/240
Input power frequency Hertz 50/60
Power (max/avg) Watts per sq.m 500/200
Grey scale level bits 16
