| Place of Origin: | China |
|---|---|
| Brand Name: | Conwin LED Display |
| Certification: | CE-EMC, CE-LVD, RoHS, ETL, FCC |
| Model Number: | Ei-A Series |
| Minimum Order Quantity: | 1sqm |
| Price: | Negotiable |
| Packaging Details: | Wooden Box |
| Delivery Time: | 15days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 1,000sqm/month |
| Pixel Pitch: | P2mm-P5mm | Material: | Steel |
|---|---|---|---|
| Refresh Rate: | 3840Hz | Module Size: | 320X160mm |
| Service Type: | Front/Rear | System: | Nova Star |
| Highlight: | Permanent Indoor LED Video Wall,Indoor LED Video Wall 3840Hz,320X160mm LED Module Panel |
||
Indoor Permanent Install LED Display LED Video Wall 320X160mm LED Module
High Resolution Indoor Full Color Led Display Advertising Led Video Wall
Indoor Fixed LED Display Screen
Application:
Indoor Ei-A Series is mainly used in enterprises, institutions, sports venues, the ticket hall, hotels, securities companies, schools, stage, public security, shopping centers and other fields.
Features and Advantages:
- Support HD 2K 4K Video Capability, bring you absolute visual experience
- Multiple Creative Application Available
- Apply for Various Location
Can be used as the indoor stage Led display, dance floor, stadium LED display, sky backdrop curtain, fixing advertising LED display, showcase LED display, etc.
- Simple and Fast installation
- Pixel Pitch:P2mm P2.5mm, P3.076mm, P4mm and P5mm
- Brand SMD LEDs, high contrast and high reliability
- Greyscale: 14-16bits
- Cabinet size: Could be customized according to led module size 320X160mm
- Service type: Magnetic front service
- Refresh Rate: 3840Hz
- Brightness: >600nits
- Wide View angle 160/160 H/V
- LED Module Size 320X160mm, support magnetic front service
- Different Cabinet design ,could be customized according to required.
Major economic cabinet design with below design
1. Simple cabinet without rear door(size could be different according to LED Module size 320X160mm)
2. Cabinet without rear door(size could be different according to LED Module size 320X160mm)
Rear door design could be customized. Steel cabinet or aluminum cabinet could be choosed.
Also for the power/signal plug could be design or added
- High refresh, High grey scale and High contast ratio, Ultimate visual enjoyment
- Different Installation type supported
Parameters:
| Model | Ei-A2 | Ei-A2.5 | Ei-A3 | Ei-A4 | Ei-A5 |
| Pixel Pitch | 2mm | 2.5mm | 3.0769mm | 4mm | 5mm |
| Pixel Configuration | SMD1515 | SMD2121 | SMD2121 | SMD2121 | SMD2121 |
| Pixel Density | 250000 pixels/m2 | 160000 pixels/m2 | 105625 pixels/m2 | 62500 pixels/m2 | 40000 pixels/m2 |
|
Module Dimensions (W x H)(mm) |
320 x 160 | 320 x 160 | 320 x 160 | 320 x 160 | 320 x 160 |
| Module Resolution | 160 x 80 | 128 x 64 | 104 x 52 | 80 x 40 | 64 x 32 |
| Colors | 281 trillion | 281 trillion | 281 trillion | 281 trillion | 281 trillion |
| Contrast Ratio | 5,000 : 1 | 5,000 : 1 | 5,000 : 1 | 5,000 : 1 | 5,000 : 1 |
| Average Power Consumption | 210 W /Sqm | 210 W /Sqm | 210 W /Sqm | 210 W /Sqm | 210 W /Sqm |
| Max Power Consumption | 600 W /Sqm | 600 W /Sqm | 600 W /Sqm | 600 W /Sqm | 600 W /Sqm |
| Brightness | >600 nits | >600 nits | >600 nits | >600 nits | >600 nits |
| Refresh Rate | >3,840Hz | >3,840Hz | >3,840Hz | >3,840Hz | >3,840Hz |
| Vertical Viewing Angle | 160° | 160° | 160° | 160° | 160° |
| Horizontal Viewing Angle | 160° | 160° | 160° | 160° | 160° |
| Expected Lifetime | 100,000 Hrs | 100,000 Hrs | 100,000 Hrs | 100,000 Hrs | 100,000 Hrs |
| Servicing | Front | Front | Front | Front | Front |
| IP Rating (Front/Rear) | IP43 / IP21 | IP43 / IP21 | IP43 / IP21 | IP43 / IP21 | IP43 / IP21 |
Pictures:
Our Services
1. 20 Years professional led display manufacturer
2. Short delivery time: 5-15 working days, adjustable according to customer request
3. Wholesale price
4. OEM and ODM service
5. Customizable product upon request
