Home ProductsIndoor LED Video Wall500X1000mm Movable Indoor LED Video Wall For Stage Events Multipurpose

500X1000mm Movable Indoor LED Video Wall For Stage Events Multipurpose

500X1000mm Movable Indoor LED Video Wall For Stage Events Multipurpose
500X1000mm Movable Indoor LED Video Wall For Stage Events Multipurpose 500X1000mm Movable Indoor LED Video Wall For Stage Events Multipurpose 500X1000mm Movable Indoor LED Video Wall For Stage Events Multipurpose 500X1000mm Movable Indoor LED Video Wall For Stage Events Multipurpose
Basic Information
Place of Origin: China
Brand Name: Conwin LED Display
Certification: CE-EMC, CE-LVD, RoHS, ETL, FCC
Model Number: Ei-D Series
Minimum Order Quantity: 1sqm
Price: Negotiable
Packaging Details: Wooden box/Flight Case
Delivery Time: 15days
Payment Terms: T/T, L/C
Supply Ability: 1,000sqm/month
Contact Now
Pixel: P2-P5mm Service Type: Front/Rear
Cabinet Size: 500x1000mm Refresh: 3840Hz
Module Size: 250X250mm Weight: 13kg
Highlight:

Movable Indoor LED Video Wall

,

Stage Indoor LED Video Wall

,

Multipurpose led video wall indoor

500X1000mm indoor Movable LED Video Wall for Stage Events or Fixed LED Screen

Indoor Led Video Wall with High Definition and 3840Hz Refresh Rate

Application:

Indoor Ei-D series Led Video Wall  are widely used for stage, events, forum, convention etc, due to great resolution and color performance

Features and Advantages:

- Super easy to install and dismantle

- Adjustable angle optional

- Front or rear serviceable

- Pixel Pitch: P2.604,P2.976mm,P3.91mm, P4.81mm
- Quality and High Contrast SMD LEDs, Wide viewing angle: 160°/ 160°.
- Greyscale: 14-16bits with NOVA system
- Cabinet size: 500x1000mm Die Cast Aluminum

- Cabinet Material: Die Cast Aluminum Cabinet, 13kg Weight

- Refresh Rate: 3840Hz

- Curve Installation: Yes, Concave and Convex Available

- Corner Protector: Available

500X1000mm Movable Indoor LED Video Wall For Stage Events Multipurpose 0

500X1000mm Movable Indoor LED Video Wall For Stage Events Multipurpose 1

500X1000mm Movable Indoor LED Video Wall For Stage Events Multipurpose 2







500X1000mm Movable Indoor LED Video Wall For Stage Events Multipurpose 3

500X1000mm Movable Indoor LED Video Wall For Stage Events Multipurpose 4



Parameters:

Model Di-HK2.6 Di-HK2.9 Di-HK3.9 Di-HK4.8
Pixel Pitch 2.604mm 2.976mm 3.91mm 4.81mm
Pixel Configuration SMD1415 SMD1415 SMD1921 SMD1921
Pixel Density 147,456 pixels/m2 112,896 pixels/m2 65,536 pixels/m2 43,264 pixels/m2
Module Dimensions (W x H) (mm) 250 x 250 250 x 250 250 x 250 250 x 250
Panel Dimensions (mm) 500 x 1000 x 80 500 x 1000 x 80 500 x 1000 x 80 500 x 1000 x 80
Modules Per Cabinet (W x H) 2 x 4 2 x 4 2 x 4 2 x 4
Module Resolution 96 x 96 84 x 84 64 x 64 52 x 52
Cabinet Resolution 192 x 384 168 x 336 128 x 256 104 x 208
Panel Material Die Cast Aluminum Die Cast Aluminum Die Cast Aluminum Die Cast Aluminum
Weight per Cabinet 13kg 13kg 13kg 13kg
Colours 281 trillion 281 trillion 281 trillion 281 trillion
Contrast Ratio 5,000 : 1 5,000 : 1 5,000 : 1 5,000 : 1
Average Power Consumption 200 W /Sqm 200 W /Sqm 200 W /Sqm 200 W /Sqm
Max Power Consumption 600 W /Sqm 600 W /Sqm 600 W /Sqm 600 W /Sqm
Brightness >1,000 nits >1,000 nits >1,000 nits >1,000 nits
Refresh Rate >3,840Hz >3,840Hz >3,840 Hz >3,840 Hz
Vertical Viewing Angle 160° 160° 160° 160°
Horizontal Viewing Angle 160° 160° 160° 160°
Expected Lifetime 100,000 Hrs 100,000 Hrs 100,000 Hrs 100,000 Hrs
Servicing Front/Rear Front/Rear Front/Rear Front/Rear
IP Rating (Front/Rear) IP 43 IP 43 IP 43 IP 43
Operating Temp/Humidity -20ºC - 50ºC / 10% - 90% -20ºC - 50ºC / 10% - 90% -20ºC - 50ºC / 10% - 90% -20ºC - 50ºC / 10% - 90%
Storage Temp/Humidity -20ºC - 50ºC / 10% - 90% -20ºC - 50ºC / 10% - 90% -20ºC - 50ºC / 10% - 90% -20ºC - 50ºC / 10% - 90%

Pictures

500X1000mm Movable Indoor LED Video Wall For Stage Events Multipurpose 5

500X1000mm Movable Indoor LED Video Wall For Stage Events Multipurpose 6

500X1000mm Movable Indoor LED Video Wall For Stage Events Multipurpose 7

Our Services

1. 20 Years professional led display manufacturer

2. Short delivery time: 5-15 working days, adjustable according to customer request
3. Wholesale price

4. OEM and ODM service
