| Place of Origin: | China |
|---|---|
| Brand Name: | CONWIN |
| Certification: | CE,ROHS |
| Model Number: | T8 |
| Minimum Order Quantity: | 1 |
| Packaging Details: | wooden box or carton |
| Delivery Time: | 5-8 working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 2000sqm/month |
| Type: | Fixed | Pixel Pitch: | P3.91/P4.81/P6.25/P7.8/P10.4 |
|---|---|---|---|
| Cabinet Material: | Aluminum | Width: | 180 Mm |
| Led Type: | SMD | Pixel Composition: | 1R 1G 1B |
| Driving Way: | Static | Resolution: | 10,000 Dots/sq.m |
| Standard Cabinet: | 1000 Mm X 1000 Mm | Scan Method: | 1/2 |
| Driving Method: | 1/8 Scan | Spare Parts: | 3% |
| Supplier Type: | Original Manufacturer, ODM, OEM | Installations: | Hanging, Floor-mounted, Side-installing |
| Highlight: | Outdoor Waterproof LED Display Screen,Full Color LED Video Wall,P3.91 Waterproof LED Display Screen |
||
Energy Saving High Definition P3.91 P4.81 P6.25 P7.8 P10.4 Full Color LED Video Wall Outdoor Waterproof LED Display LED Screen
Products Description:
1.T Series is designed for outdoor use, 2.80mm thickness & 27kg/sqm, greatly reduce the structure load;
| Model | FG3.91 | FG4.81 | FG6.25 | FG7.8 | FG10.4 |
| LED configuration | SMD1921 | SMD1921 | SMD2727 | SMD2727 | SMD2727 |
| Pixel pitch(mm) | 3.91 | 4.81 | 6.25 | 7.8 | 10.4 |
| Module size(mm) | 500*250 | ||||
| Cabinet size(mm) | 1000*1000*90 | ||||
| Cabinet material | Die-casting Aluminium | ||||
| Weight(KG) | 23.5 | ||||
| Viewing angle | 140°/120° | ||||
| Supply voltage | AC110-240V/60Hz | ||||
| Average power(w/m2) | 185 | 185 | 185 | 185 | 185 |
| Max consumption(w/m2) | 550 | 550 | 550 | 550 | 550 |
| Refresh rate(HZ) | ≥3840 | ||||
| Brightness(cd/m2) | 5000 | 5500 | 5500 | 5800 | 6000 |
| Drive mode(S) | 1/8 | 1/13 | 1/5 | 1/4 | 1/2 |
| Life(H) | 100000 | ||||
| Waterproof | IP65 | ||||
| Maintenance type | Front / Rear | ||||
