| Place of Origin: | China |
|---|---|
| Brand Name: | Conwin LED Display |
| Certification: | FCC, CE, ROHS |
| Model Number: | D-LK4.8 |
| Minimum Order Quantity: | 1sqm |
| Price: | Negotiable |
| Packaging Details: | Plywood box/Flight case |
| Delivery Time: | 15 working days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 1000 sqm per month |
| Type: | Outdoor Rental LED Screen | Pixel Pitch: | P4.81mm |
|---|---|---|---|
| Cabinet Size: | 500x500 | Service: | Front/Rear |
| Weight: | 8kg | Module Size: | 250x500mm |
| Highlight: | Customized Outdoor Rental LED Display,Outdoor Rental LED Display P4.81mm |
||
Outdoor P4.81mm Stage Rental LED Display 5000nits LED Video Wall
5000nits Outdoor Rental LED Video Wall With Removable Power Box
Outdoor P4.81mm 500x1000mm Die Cast Aluminum Cabinet High Brightness 5000nits With Removable Power Box
Application Of Outdoor Rental LED Video Wall
Make full use of the stage and make bold innovations to expand the means of expression of the stage. At present, when visual art dominates artistic expression, it is impossible to meet the aesthetic needs of the audience only by means of traditional dance beauty, which must be presented by stage devices and various technical means. Vehicle platform, lifting platform, hanging and other mechanical devices can be loaded with display screen, combined with control technology, to produce a variety of stage effects. The platform with transparent screen was used in the 8-minute theatrical performance of the closing ceremony of the Pyeongchang Winter Olympic Games. The high-precision robot arm (commonly known as the mechanical arm), which was used in the industrial field in the past, is now also used in stage performances. The led screen can be spliced and rotated under the control of the mechanical arm to form various shapes and pictures over the stage. It can also be placed in any position of the actors, such as front, back, left and right, to participate in performances and interact with the actors. It can also replace the curtain, strip curtain and so on. The use of large robotic arms makes the led screen not only as a background, but also participate in the performance, making the stage a changing three-dimensional multi-dimensional space.
Quick detail Of Outdoor Rental LED Screen
- Pixel Pitch: 2.6mm, 2.9mm, 3.91mm, 4.81mm
- Waterproof brand SMD LEDs, high brightness and high reliability
- Greyscale: 14bits - 16bits
- Cabinet size: 500x500mm and 500x1000mm Die Cast Aluminum Cabinet
- Service type: Waterproof and magnetic front service
- PSU: Pin connection independent power box, easily and evenly remove and put on
- Refresh Rate: 3840Hz
- Ingress Rate: IP65 Outdoor standard and magnetic front service
- Quality Certificate:CE, RoHS,FCC, ETL
- Brightness:>5000cd/sqm
- Curve Installation: Rotary lock for +- 15 degree Concave and Convex shape
- Corner Protector: Semi-auto Corner Protector, gently push and release the protector for the max security of LEDs
Paramters:
| Model | D-LK2.6 | D-LK2.9 | D-LK3.9 | D-LK4.8 |
| Pixel Pitch | 2.604mm | 2.976mm | 3.91mm | 4.81mm |
| Pixel Configuration | SMD1415 | SMD1415 | SMD1921 | SMD1921 |
| Pixel Density | 147,456 pixels/m2 | 112,896 pixels/m2 | 65,536 pixels/m2 | 43,264 pixels/m2 |
| Module Dimensions (W x H) (mm) | 250 x 250 | 250 x 250 | 250 x 250 | 250 x 250 |
| Panel Dimensions (mm) | 500 x 500 x 80 | 500 x 500 x 80 | 500 x 500 x 80 | 500 x 500 x 80 |
| Modules Per Cabinet (W x H) | 2 x 2 | 2 x 2 | 2 x 2 | 2 x 2 |
| Module Resolution | 96 x 96 | 84 x 84 | 64 x 64 | 52 x 52 |
| Cabinet Resolution | 192 x 192 | 168 x 168 | 128 x 128 | 104 x 104 |
| Panel Material | Die Cast Aluminum | Die Cast Aluminum | Die Cast Aluminum | Die Cast Aluminum |
| Weight per Cabinet | 8kg | 8kg | 8kg | 8kg |
| Colours | 281 trillion | 281 trillion | 281 trillion | 281 trillion |
| Contrast Ratio | 5,000 : 1 | 5,000 : 1 | 5,000 : 1 | 5,000 : 1 |
| Average Power Consumption | 280 W /Sqm | 260 W /Sqm | 250 W /panel | 220 W /panel |
| Max Power Consumption | 680 W /Sqm | 650 W /Sqm | 620 W /panel | 600 W /panel |
| Brightness | >5,000 nits | >5,000 nits | >5,000 nits | >5,000 nits |
| Refresh Rate | >3,840Hz | >3,840Hz | >3,840 Hz | >3,840 Hz |
| Vertical Viewing Angle | 160° | 160° | 160° | 160° |
| Horizontal Viewing Angle | 160° | 160° | 160° | 160° |
| Expected Lifetime | 100,000 Hrs | 100,000 Hrs | 100,000 Hrs | 100,000 Hrs |
| Servicing | Front/Rear | Front/Rear | Front/Rear | Front/Rear |
| IP Rating (Front/Rear) | IP 65 | IP 65 | IP 65 | IP 65 |
| Operating Temp/Humidity | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% |
| Storage Temp/Humidity | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% |
