Outdoor Football Stadium Perimeter LED Screen SMD LED Type P8 Portable Waterproof

Outdoor Football Stadium Perimeter LED Screen SMD LED Type P8 Portable Waterproof
Outdoor Football Stadium Perimeter LED Screen SMD LED Type P8 Portable Waterproof Outdoor Football Stadium Perimeter LED Screen SMD LED Type P8 Portable Waterproof Outdoor Football Stadium Perimeter LED Screen SMD LED Type P8 Portable Waterproof Outdoor Football Stadium Perimeter LED Screen SMD LED Type P8 Portable Waterproof
Basic Information
Place of Origin: China
Brand Name: CONWIN
Certification: CE,ROHS
Model Number: Q8
Packaging Details: wooden box or carton
Delivery Time: 5-8 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 2000sqm/month
Contact Now
Led Type: SMD Cover: Soft Cover
Feature: Full Color Life Span: 100000hours
Configuration: DIP346 Power Supply: Meanwell
Dimension: 960*960*100 Size: 160mm×160mm
Leds: SMD 3in1 Viewing Angle: 140°/140°
Weight: 45kg
Highlight:

P8 Stadium LED Screen

,

Waterproof Stadium LED Screen

,

Outdoor Stadium LED Screen

P8 Portable Full Color Advertising LED Digital Sign Board Waterproof Outdoor Football Stadium Perimeter LED Screen Display



Protection for Players

Rubber pads and the module soft mask can keep the athletes safe from sharp objects while protecting the LED display. With a special design, the perimeter screen can be pushed to both sides quickly to form an exit as an emergency access.

Never Blackout

N+1 power backup and receiving card dual backup can keep the screen running steadily and efficiently.

Superb Picture Quality

The 7680Hz high refresh rate and 6000:1 contrast ratio ensure consistently smooth playback. 6000nits brightness and 140° horizontal view remain perfect in-camera visuals during live streaming or broadcast.





Products Parameters

Model
P6.25
P8.33
P10
Physical density (dots/sqm)
25600
14400
10000
LED Type
SMD2727
SMD2727
SMD2727
Module resolution
64*48
48*36
40*30
Module Dimension
400*300
400*300
400*300
Module quantity (W×H)
4*3
4*3
4*3
Panel resolution (W×H)
256*144
192*108
160*90
Panel size (mm)
1600*900*98
1600*900*98
1600*900*98
Flatness (mm)
≤0.1
≤0.1
≤0.1
Maintenance mode
Front & Rear
Front & Rear
Front & Rear
Brightness (nits)
6500
6500
6500
Color temperature (K)
1000-18500 optional
1000-18500 optional
1000-18500 optional
Cabinet weight
45
45
45
Viewing angle (V/H)
140°/160°
140°/160°
140°/160°
Contrast ratio
10000:1
10000:1
10000:1
Frame-changing frequently
50/60
50/60
50/60
Drive mode
Static 1/6 scale
Static 1/3 scale
Static 1/2 scale
Refresh rate
3840
3840
3840
Max power consumption (w/m²)
600
600
600
Avg. power consumption (w/m²)
120-200
120-200
120-200
Protection grade
IP65
IP65
IP65
Electric power requirements
AC90-264V,47-63Hz
Working Temp/Humidity(℃/RH)
-20~60℃/10%~85%
Outdoor Football Stadium Perimeter LED Screen SMD LED Type P8 Portable Waterproof 0
Outdoor Football Stadium Perimeter LED Screen SMD LED Type P8 Portable Waterproof 1
Outdoor Football Stadium Perimeter LED Screen SMD LED Type P8 Portable Waterproof 2
Outdoor Football Stadium Perimeter LED Screen SMD LED Type P8 Portable Waterproof 3
Outdoor Football Stadium Perimeter LED Screen SMD LED Type P8 Portable Waterproof 4
Outdoor Football Stadium Perimeter LED Screen SMD LED Type P8 Portable Waterproof 5
Outdoor Football Stadium Perimeter LED Screen SMD LED Type P8 Portable Waterproof 6
Outdoor Football Stadium Perimeter LED Screen SMD LED Type P8 Portable Waterproof 7
Application
Outdoor Football Stadium Perimeter LED Screen SMD LED Type P8 Portable Waterproof 8
Outdoor Football Stadium Perimeter LED Screen SMD LED Type P8 Portable Waterproof 9
Outdoor Football Stadium Perimeter LED Screen SMD LED Type P8 Portable Waterproof 10
Outdoor Football Stadium Perimeter LED Screen SMD LED Type P8 Portable Waterproof 11
Outdoor Football Stadium Perimeter LED Screen SMD LED Type P8 Portable Waterproof 12
Outdoor Football Stadium Perimeter LED Screen SMD LED Type P8 Portable Waterproof 13
